PROFILO LED 80 WH

OUTPUT

• �� Single high-power White 3000 K LED
• �� CRI > 90
• �� Also available with 4000 K and 5000 K LED
• �� LED lifespan: 50000 hours (L70B10)

OPTICAL GROUP

• �� 20°- 36° linear zoom
• �� High definition zoom lens with double optical condenser lens

GOBOS

• �� Gobo type M
• �� Ø external: 66 mm
• �� Ø of image: 48 mm
• �� Thickness: from 0.2 to 3 mm

CONTROL

• �� DMX 512 / RDM or Manual control
• �� Multi-function 4-digit 7-segment LED display + 4 soft keys
• �� Firmware updatable via DTS firmware uploader dongle

POWER SUPPLY

• �� Electronic Wide-range 100-240 Vac 50-60 Hz
• �� Power consumption: 100 W max
• �� Power Factor: PF >0.95

DMX

• �� 2 DMX channels (default)
• �� 3 DMX channels
• �� 1 DMX channel

CIRCUITS PROTECTIONS

• �� Overvoltage circuit protection and overtemperature circuit protection

CONNECTIONS

• �� Power supply: PowerCON In/Out panel connectors
• �� DMX: XLR 5-pole In/Out panel connectors

TEMPERATURE

• �� Operating: -10° +40° C

PHYSICAL

• �� Finishing: Black
• �� Internal system with four removable shutters
• �� Yoke featuring an exclusive round flange + clutch system
• �� Weight: 6.3 Kg (13.9 lbs)
• �� IP rating: IP20

TEST AND CERTIFICATION

• �� CE

ACCESSORIES INCLUDED

• �� 1 x PowerCON female cable connector (code 0520P014)
• �� 1 x XLR 5 pins male cable connector (code 0508B028)
• �� 1 x XLR 5 pins female cable connector (code 0508B027)
• �� 1 x Filterframe – Black finish – already mounted on the unit (code 02M00426.46)
• �� 4 x Shutter blades (single blade code 02SK0335)

ACCESSORIES ON REQUEST

• �� Gobo holder (code 03.TA224)
• �� Iris/diaphram (code 03.TA223)
• �� Outdoor DMX cable 2 x 0,25 mm2 – Flame retardant (code 0509C158)
• �� Universal Hook Clamp – Max load 40 Kg – 88 lbs (code 0521A047)
• �� Safety cable – 3 x 600 mm – max. capacity load 30 Kg (code 0521A010)
• �� DTS firmware uploader dongle (code 03.LA.206)

• �� Track adapter – black finishing (code 03.LA.235)
